HRT-710 - Modbus/HART Gateway
Levertijd:
2~7 dagen
SKU
HRT-710
Modbus/HART Gateway
● Support HART Short/Long frame
● Support HART Burst mode
● Allow two HART Masters
● Support Modbus RTU and ASCII format
● Support Modbus Slave mode
● Isolated COM 1: RS-232/422/485
● Provide LED indicators
● Built-in Watchdog
● DIN-Rail Mountable
The HRT-710 Gateway is specially designed for the master device of HART protocol. It allows the Modbus master to access the HART devices. These HART devices may be a transmitter, an actuator and so forth. In addition, we also provide the utility software for users to configure the HRT-710. By using this module, users can put their HART devices into Modbus network very easily.
APPLICATIONS
● Industrial Automation
● Factory Automation
● Process Automation
UTILITY:
● Read/Write HART device by HART command
● Provide diagnostic information
● Read/Write module configuration of the HART-710
● Show Modbus address of HART command
Meer informatie
Art.nr.
HRT-710
Fabrikant
ICPDAS
Hardware
| CPU | 32 bit, 100MHz or compatible |
| Flash | 512 Kb |
| SRAM | 64 Kb |
| EEPROM | 16Kb |
| Watchdog | Watchdog IC |
| ESD Protection | 4kV class A |
UART Interface
| COM 1 | RS-232(3 wires)/RS-422/RS-485 |
| COM 1 Connector | 9-pin screwed terminal block |
| Baud Rate | Up to 115200 |
| Protocol | Modbus RTU / Modbus ASCII |
HART Interface
| HART Interface | 2-pin screwed terminal block |
| HART Channel | 1 |
Power
| Power Supply | Unregulated +10 ~ +30V DC |
| Protection | Power reverse polarity protection, Overvoltage brown-out protection |
| Power Consumption | 1 W |
Mechanical
| Installation | DIN-Rail or Wall Mounting |
| Dimensions (w x l x h) | 72 x 33 x 122mm |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +85 °C |
| Humidity | 5 ~ 95% |
