ICPDAS CAN-8224

Levertijd:
2~7 dagen
SKU
CAN-8224

DeviceNet Embedded Device with 2 I/O Expansions

● Number of Nodes: 64 max.
● Baud Rate: 125 K, 250 K, 500 K
● Support Message Groups: Group 2 only Server
● I/O Operating Modes: Poll, Bit-Strobe, Change of State / Cyclic
● Device Heartbeat & Shutdown Message
● Produce EDS file Dynamically
● No. of Fragment I/O: 128 Bytes max. (Input / Output)
● MAC ID Setting by Rotary Switch
● Baud Rate Setting by Rotary Switch
● Status LED: NET, MOD, PWR

DeviceNet is one kind of the network protocols based on the CAN bus and mainly used for embedded network for machine control, such as textile machinery, printing machines, injection molding machinery, or packaging machines, etc. DeviceNet is a low level network that provides connections between simple industrial devices (sensors, actuators) and higher level devices (controllers). It allows direct peer to peer data exchange between nodes in an organized and, if necessary, deterministic manner. DeviceNet defines a connection-based scheme to facilitate all application communications. A DeviceNet connection provides a communication path between multiple endpoints. The endpoints of a connection are applications that need to share data.

The ICPDAS 8000 Series I/O Unit CAN-8224 main control unit is specially designed for the slave device of DeviceNet protocol. It follows the Specification of DeviceNet. In order to expand I/O channel more flexible, an CAN-8x24 supports 1/2 slot(s) for I/O expansion and suits with a lot of ICP DAS DI/AI/DO/AO modules.Users can choice DI/DO/AI/AO modules of I-87K series or I-8000 series to fit the customized practice applications.

In addition, we also provide CAN Slave Utility to allow users to create the EDS file dynamically. The EDS file is based on DeviceNet and can be compatible with different DeviceNet master interfaces. The application architecture is as image on the right.



https://fieldworks.nl/media/imageproducts/icpdas/CAN-8223_1.jpg



APPLICATIONS

● Automotive
● Food & Beverage
● Packaging
● High-speed Assembly
● Pulp & Paper
● Semiconductor Fabrication
● Control System



https://fieldworks.nl/media/imageproducts/icpdas/photo2.gif



UTILITY

In the ICPDAS 8000 Series I/O Unit CAN-8224 device, ICPDAS provides CAN Slave Utility to produce the specific EDS file with the plugged in modules in off-line mode. After finishing the utility configuration, it can create the EDS file. There is also much DeviceNet information of the CAN-8x24 in the EDS file. It is not only for DeviceNet master interface but also for users to know more information about the slave device. Users also can use the default configuration for general DI/DO/AI/AO. And users only need to set the MAC ID and Baud rate by hardware rotary switch. Then, after wire connection and the CAN-8x24 powered on, it can work normally on the CAN bus network through DeviceNet protocol.



DESIGN FLOWCHART

The following simple steps show how to use CAN-8x24 in DeviceNet protocol.

https://fieldworks.nl/media/imageproducts/icpdas/CAN-8223_2.gif

Meer informatie
Art.nr.
CAN-8224
Fabrikant
ICPDAS
Hardware
CPU 80186, 80 MHz or compatible
SRAM/Flash/EEPROM 512 KB / 512 KB / 16 KB
DPRAM 8 KB
NVRAM 31 bytes (battery backup, data valid for up to 10 years)
RTC (Real Time Clock) Yes
Watchdog CPU built-in
Expansion Slot 2 slots
CAN Interface
Controller NXP SJA1000T with 16 MHz clock
Transceiver NXP 82C250
Channel Number 1
Connector 5-pin screwed terminal block (CAN_GND, CAN_L, CAN_SHLD, CAN_H, CAN_V+)
Baud Rate 125 k, 250 k, 500 k
Transmission Distance Depend on baud rate (for example, max. 500 m at 125 kbps)
Isolation 3000 VDC for DC-to-DC, 2500 Vrms for photo-couple
Terminator Resistor Jumper for 120 Ω terminator resistor
Specification ISO-11898-2, CAN 2.0A and CAN 2.0B
Protocol
DeviceNet Volumn I v2.0, Volumn II v2.0
Predefined Master/Slave Connection set
LED Indicators
Round LED PWR LED, NET LED, MOD LED
Power
Power Supply Unregulated +10 ~ +30 VDC
Protection Power reverse polarity protection, Overvoltage brownout protection
Power Consumption 2 W
Mechanical
Installation DIN-Rail or Wall Mounting
Dimensions (w x l x h) 95 x 132 x 91mm
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -30 °C ~ +80 °C
Humidity 10 ~ 90% RH, non-condensing
