CWE Transducer Amplifier PA-931
Levertijd:
3~4 weken
SKU
PA-931
Low Cost Transducer Amplifier
● Low-Cost Alternative to the PM-1000
● High Gain to x1100
● Built-In, Adjustable Excitation
● 2-Position Filter Switch
● Continuously Variable Sensitivity of x1 to x11
● Industry Standard Canon WK6-32S Input Connector
The CWE Transducer Amplifier PA-931 offers an economical alternative to the PM-1000, and provides the same level of compatibility with a wide range of resistive and solid state transducers. The PA-931 is a good choice for cost-sensitive applications that don't demand the PM-1000's high degree of measurement flexibility. Instead of the PM-1000's nine-step attenuator, the PA-931's design substitutes a ten-turn sensitivity control and a 10x/100x range switch. The six-position, low-pass filter switch on the PM-1000 is replaced by a three-position switch on the PA-931, providing passive mean and 1kHz selections. Up to six CWE Transducer Amplifier PA-931 modules will fit in any DI-1000 Series module cage. Like the PM-1000, the PA-931 IS NOT designed for human-patient-connected (clinical) blood pressure applications.
Art.nr.
PA-931
Fabrikant
CWE
Land van herkomst
Verenigde Staten
Specifications
Input Type | Differential, balanced to chassis common |
Transducer Compatiblity | Statham, Gould, Grass, etc. |
Common Mode Rejection | >100 db @ 60 Hz |
Filter Frequency | 0.1 (Mean), 1000 Hz, Off |
Filter type, Slope | -6 db/octave |
Excitation Voltage | +4 to +10 VDC adjustable |
Balance Control | ±0.2, ±0.05 VDC, 10-turn (internally selectable ranges) |
Sensitivity | x10-x1100, 2 ranges |
Sensitivity Knob | 10-turn, 1-11x |
Low-pass Filter | 3-position |
Input Connector | Canon WK6-32S, BNC |
Output Range | ±10 V |
Output Connector (Rear Panel) | Amphenol, 7-pin plug |
Power Requirements
±12 VDC @ 50 mA
Size (W x H x D)
69.9 x 127.0 x 254.0 mm
