Axiomtek Railway Panel PC GOT710-837

Levertijd:
3~4 weken
SKU
GOT710-837

10.4” EN50155 Railway Fanless Touch Panel PC with Intel® Atom™ Processor E3845 1.91 GHz (-25°C ~ +70°C)

● Sunlight readable 10.4" SVGA high brightness (1000 nits)
● Fanless with Intel® Atom™ processor E3845 1.91 GHz
● Alternative keypad control in front bezel
● All lockable connectors design
● Auto-dimming for detecting the different environment
● Wide operating temperature: -25°C ~ +70°C
● EN50155 certificated for railway application

The GOT710-837 is equipped with a 10.4-inch SVGA TFT LCD display with high brightness LED backlight (1000 nits), which can allow a train operator to easily read any operational status messages, even under direct sunlight. Design for ease of use and maintenance, this all-in-one industrial touch panel PC also has an alternative keypad control on the front panel for easy access and cleaning purposes. This feature-rich panel PC has an IP65 rating, M12 connectors and is EN50155 certified. The electronics inside the panel PC are well protected from harsh operating conditions and can withstand high vibrations, dust, spillage and high level of humidity. The GOT710-837 is particularly suitable for demanding HMI applications in the railway sector, including tasks like monitoring and controlling train functions such as speed, temperature, and security, or for fleet management.

GOT710-837
is used to keep the train driver informed about the status of the train’s functions. Its design allows it to be deployed in environment with an extended
temperature (-25°C ~ 70°C) and it also complies with the EMC, shock and vibration test requirements of European standard EN50155 for railway applications. GOT710-837 is equipped with 10.4" TFT ruggedized touch panel computer and all lockable connectors are perfect choice for Human Machine Interface (HMI) in railway environments. The 10.4" railway touch panel PC includes a comprehensive feature set with one CAN Bus, DIO, audio, two Ethernet ports, USB ports and RS-232/422/485.

Railway application-EN50155 certificated
Railway power module design support 10ms interruption, EMI EN55022 CLASS A filter, Over/short current protection for its railway application.

Sunlight readable design
Its sunlight readable technology with LED tech high brightness 1000 nits color display allows the screen legible even strong sunlight.

Meer informatie
Art.nr.
GOT710-837
Fabrikant
Axiomtek
Land van herkomst
Taiwan
Front Bezel
IP65, NEMA 4 rugged protection, aluminum front bezel
LCD Panel
Display Type 10.4" SVGA TFT LCD
Brightness (cd/m2 )

1000 nits

Resolution 800 x 600 pixels
Viewing Angle (H/V) 160°/160°
Main System
CPU Intel® Atom™ processor E3845 1.91 GHz (Bay Trail)
System Memory

DDR3 4 GB (default) or 8 GB memory onboard

BIOS

AMI with Axiomtek standard features:
SmartView, Ethernet
Boot ROM (RPL & PXE), customer
CMOS backup

Storage
16GB Flash onboard
1 x msata
Watchdog Timer 255 levels, 1~255 sec.
Onboard Graphics Integrated in Intel® GFX
I/O Connector
2 x RS-232/422/485 with isolated 1.5KV (M12, A-coded)
2 x RJ-45 for Gigabit LAN with isolated 1.5KV (M12, X-coded)
2 x USB 2.0 (M12, A-coded)
1 x DC for power input with isolated 1.5KV (M12, A-coded)
1 x Audio: Line out, Line in, speaker out (D-sub)
1 x DIO (6 input/2 output) with isolated 1.5KV (phoenix type)
1 x CAN bus with isolated 1.5KV (D-sub)
Expansion Interface
2 x PCIe Mini Card slot
Touchscreen
Alternative 5-wire resistive touch panel or keyboard
Power Supply
16.8V to 30V DC or 77V to 137.5 VDC 10ms hold up time (S2)
Grootte
310 x 65.05 x 216 mm
Weight (net/gross)
2.4 kg / 5 kg
Environmental
Operation Temperature -25 °C ~ +70 °C
Storage Temperature -30°C ~ +80°C
Humidity 10% ~ 95% @ 40°C, non-condensing
Certification

EN50155 Railway, EN50121-3-2 Railway EMC,
EN61373 Railway Shock/Vibration,
EN45545 Compliance with keypad UIC612-01

Operating System
WES 7
WES 8
Windows® 8
Windows® 7
