Programmable Gateway & Converter
The DS/PDS series device server (Serial-to-Ethernet gateway) adds Ethernet and Internet connectivity to any RS-232 and RS-422/485 device, and eliminates the cable length limitation of legacy serial communication. By using the VxComm Driver/Utility, the built-in COM port of the device servers can be virtualized as a standard PC COM port in Windows. Therefore, users can directly and transparently access or monitor serial devices via the Internet/Ethernet.
In the past decades, a great number of serial devices such as PLCs, bar code readers, RFID readers, meters and motion controllers, etc., have been widely used in various applications. As advances in communication technologies continue to drive the improvement of data accessibility and remote operation ability, many industries feel the urge to upgrade their legacy serial communications to Ethernet network connections. ICP DAS device server products are the best choice for implementing this scenario in a robust, reliable and cost-effective way.
ICPDAS I-7188E2D-MTCPModbus/TCP Embedded Controller with display (Ethernet enables Modbus commands to run over TCP/IP)
Modbus Firmware Features:
● Supports VxComm technique for every COM port of controllers
● Allowed multi-client (or master) access simultaneously
● Firmware modifiable
Modbus SDK (in C language) Features:
● Supports extra user-defined command protocol (TCP/IP)
● Register based programming method (easy to use)
● Provides user-defined registers
● Can link to Modbus/TCP slave devices
● Can link to Modbus/RTU slave devices
● Can link to non-Modbus/RTU serial devices
● Xserver SDK compatible
ICPDAS I-7188EX-512 CREmbedded Internet/Ethernet Controller with one Ethernet port, one RS-232 port, One RS-485 / 512K SRAM / 512K FLASH,and several optional user defined I/O
● AMD 80188-40 embedded CPU or compatible
● Supports a variety of TCP/IP features, including TCP, UDP, IP, ICMP,ARP
● 10BASE-T NE2000 compatible Ethernet Controller
● Reloadable Operating Software
● Remote Configuration
● Diagnostics
● 64-bit hardware unique serial number inside
● COM driver support interrupt & 1K QUEUE Input & Output buffer
● COM port: COM1, COM2
● Built-in RTC, NVRAM, EEPROM
● User defined 14 I/O lines
● Built-in I/O expansion bus interface
● Can add on one expansion board only
● Built-in self-tuner ASIC controller on RS-485 port
● 7-segment LED display for I-7188EXD
● Built-in MiniOS7
● Program download port: COM1 or Ethernet Port
I-7550E PROFIBUS/Ethernet ConverterICPdas PROFIBUS/Ethernet Converter(RoHS)
● DP-V0 Slave
● Transmission Rate (kbps) 9.6, 19.2, 45.45, 93.75, 187.5, 500, 1500, 3000, 6000, 12000
● Automatically sets transmission rates
● Max Input/Output of Data is 240Bytes
● Web Configuration
● 10/100 Base-TX
● 2500 Vrms Network Isolation Protection
● 3000 VDC DC Protection Isolation Protection on PROFIBUS side
ICPDAS GW-7238DJ1939 to Modbus TCP Server / RTU Slave Gateway
● RoHS Design
● Provide PWR / ERR / J1939 / MODBUS indication LEDs
● The built-in jumper to select 120 ohm terminal resister of CAN bus
● Watchdog inside
ICPDAS I-7530A-MRModbus RTU to CAN converter
● RoHS Design
● Fully compatible with ISO 11898-2 standard
● Programmable CAN bus baud rate from 10 kbps to 1 Mbps or user-defined baud rate
● Support CAN bus acceptance filter configuration
● Support firmware update via RS-232
● Provide utility tool for module setting and CAN bus communication testing
● Built-in jumper to select 120Ω terminator resistor
● CAN buffer: 128 data frames ; UART buffer: 256 bytes
● Power, data flow and error indicator for CAN and UART status
● Hardware Watchdog design
● Convert CAN message to specific ASCII command string (Normal mode)
● Convert specific ASCII command string to CAN message (Normal mode)
● Provide the transparent communication between the RS-232/485/422 devices via CAN bus (Pair-connection mode)
● Support function code 0x03/0x04/0x10 of Modbus RTU command for reading and writing CAN message (Modbus RTU mode)
ICPDAS tGW-734(i)Tiny Modbus/TCP to RTU/ASCII gateway with PoE and 2 RS-232 and 1 485 Ports
● Cost-effective Modbus/TCP to RTU/ASCII Gateway
● Supports Modbus/TCP master and slave
● Supports Modbus RTU/ASCII master and slave
● Contains a 32-bit MCU that efficiently handles network traffic
● 10/100 Base-TX Ethernet, RJ-45 x 1 (Auto-negotiating, auto MDI/MDIX, LED Indicators)
● Includes redundant power inputs: PoE (IEEE 802.3af, Class 1) and DC jack
● Allows automatic RS-485 direction control
● Supports TCP, UDP, HTTP, DHCP, BOOTP and TFTP protocols
● Supports UDP responder for device discovery
● Allows easy firmware update via the Ethernet
● Contains a tiny Built-in Web server for configuration
● Terminal block connector for easy wiring
● Tiny form-factor and low power consumption
● RoHS compliant with no Halogen
● Made from fire retardant materials (UL94-V0 Level)
ICPDAS tGW-724(i)Tiny Modbus/TCP to RTU/ASCII gateway with PoE and 1 RS-232 and 1 485 Ports
● Cost-effective Modbus/TCP to RTU/ASCII Gateway
● Supports Modbus/TCP master and slave
● Supports Modbus RTU/ASCII master and slave
● Contains a 32-bit MCU that efficiently handles network traffic
● 10/100 Base-TX Ethernet, RJ-45 x 1 (Auto-negotiating, auto MDI/MDIX, LED Indicators)
● Includes redundant power inputs: PoE (IEEE 802.3af, Class 1) and DC jack
● Allows automatic RS-485 direction control
● Supports TCP, UDP, HTTP, DHCP, BOOTP and TFTP protocols
● Supports UDP responder for device discovery
● Allows easy firmware update via the Ethernet
● Contains a tiny Built-in Web server for configuration
● Terminal block connector for easy wiring
● Tiny form-factor and low power consumption
● RoHS compliant with no Halogen
● Made from fire retardant materials (UL94-V0 Level)
ICPDAS CAN to Wi-Fi Converter I-7540D-WFCAN to WI-Fi Converter
● IEEE 802.11a/b/g compliant
● Wireless data transmission via WLAN
● Two different operation modes: infrastructure and ad-hoc
● Point to point or point to multi-points connection via wireless LAN
● Supports WEP, WPA and WPA2 encryption for wireless LAN
● CAN 2.0A/2.0B compliant
● Connect CAN networks via a WLAN bridge
● Communication efficiency: one-way is up to 700 fps (client->server->client), two-way 350 fps (client<=>server)
● Wireless communication: 100m (Without PA) / 300m (With PA)
ICPDAS tGW-718(i)Tiny Modbus/TCP to RTU/ASCII gateway with PoE and 1 RS-232/422/485 Port
● Cost-effective Modbus/TCP to RTU/ASCII Gateway
● Supports Modbus/TCP master and slave
● Supports Modbus RTU/ASCII master and slave
● Contains a 32-bit MCU that efficiently handles network traffic
● 10/100 Base-TX Ethernet, RJ-45 x 1 (Auto-negotiating, auto MDI/MDIX, LED Indicators)
● Includes redundant power inputs: PoE (IEEE 802.3af, Class 1) and DC jack
● Allows automatic RS-485 direction control
● Supports TCP, UDP, HTTP, DHCP, BOOTP and TFTP protocols
● Supports UDP responder for device discovery
● Allows easy firmware update via the Ethernet
● Contains a tiny Built-in Web server for configuration
● Terminal block connector for easy wiring
● Tiny form-factor and low power consumption
● RoHS compliant with no Halogen
● Made from fire retardant materials (UL94-V0 Level)
ICPDAS tGW-735(i)Tiny Modbus/TCP to RTU/ASCII gateway with PoE and 3 RS-485 Ports
● Cost-effective Modbus/TCP to RTU/ASCII Gateway
● Supports Modbus/TCP master and slave
● Supports Modbus RTU/ASCII master and slave
● Contains a 32-bit MCU that efficiently handles network traffic
● 10/100 Base-TX Ethernet, RJ-45 x 1 (Auto-negotiating, auto MDI/MDIX, LED Indicators)
● Includes redundant power inputs: PoE (IEEE 802.3af, Class 1) and DC jack
● Allows automatic RS-485 direction control
● Supports TCP, UDP, HTTP, DHCP, BOOTP and TFTP protocols
● Supports UDP responder for device discovery
● Allows easy firmware update via the Ethernet
● Contains a tiny Built-in Web server for configuration
● Terminal block connector for easy wiring
● Tiny form-factor and low power consumption
● RoHS compliant with no Halogen
● Made from fire retardant materials (UL94-V0 Level)
ICPDAS tGW-725(i)Tiny Modbus/TCP to RTU/ASCII gateway with PoE and 2 RS-485 Ports
● Cost-effective Modbus/TCP to RTU/ASCII Gateway
● Supports Modbus/TCP master and slave
● Supports Modbus RTU/ASCII master and slave
● Contains a 32-bit MCU that efficiently handles network traffic
● 10/100 Base-TX Ethernet, RJ-45 x 1 (Auto-negotiating, auto MDI/MDIX, LED Indicators)
● Includes redundant power inputs: PoE (IEEE 802.3af, Class 1) and DC jack
● Allows automatic RS-485 direction control
● Supports TCP, UDP, HTTP, DHCP, BOOTP and TFTP protocols
● Supports UDP responder for device discovery
● Allows easy firmware update via the Ethernet
● Contains a tiny Built-in Web server for configuration
● Terminal block connector for easy wiring
● Tiny form-factor and low power consumption
● RoHS compliant with no Halogen
● Made from fire retardant materials (UL94-V0 Level)
ICPDAS tGW-732(i)Tiny Modbus/TCP to RTU/ASCII gateway with PoE and 3 RS-232 Ports
● Cost-effective Modbus/TCP to RTU/ASCII Gateway
● Supports Modbus/TCP master and slave
● Supports Modbus RTU/ASCII master and slave
● Contains a 32-bit MCU that efficiently handles network traffic
● 10/100 Base-TX Ethernet, RJ-45 x 1 (Auto-negotiating, auto MDI/MDIX, LED Indicators)
● Includes redundant power inputs: PoE (IEEE 802.3af, Class 1) and DC jack
● Allows automatic RS-485 direction control
● Supports TCP, UDP, HTTP, DHCP, BOOTP and TFTP protocols
● Supports UDP responder for device discovery
● Allows easy firmware update via the Ethernet
● Contains a tiny Built-in Web server for configuration
● Terminal block connector for easy wiring
● Tiny form-factor and low power consumption
● Made from fire retardant materials (UL94-V0 Level)
ICPDAS tGW-722(i)Tiny Modbus/TCP to RTU/ASCII gateway with PoE and 2 RS-232 Ports
● Cost-effective Modbus/TCP to RTU/ASCII Gateway
● Supports Modbus/TCP master and slave
● Supports Modbus RTU/ASCII master and slave
● Contains a 32-bit MCU that efficiently handles network traffic
● 10/100 Base-TX Ethernet, RJ-45 x 1 (Auto-negotiating, auto MDI/MDIX, LED Indicators)
● Includes redundant power inputs: PoE (IEEE 802.3af, Class 1) and DC jack
● Allows automatic RS-485 direction control
● Supports TCP, UDP, HTTP, DHCP, BOOTP and TFTP protocols
● Supports UDP responder for device discovery
● Allows easy firmware update via the Ethernet
● Contains a tiny Built-in Web server for configuration
● Terminal block connector for easy wiring
● Tiny form-factor and low power consumption
● RoHS compliant with no Halogen
● Made from fire retardant materials (UL94-V0 Level)
ICPDAS tGW-712(i) - Tiny Modbus/TCP to RTU/ASCII gatewayTiny Modbus/TCP to RTU/ASCII gateway with PoE and 1 RS-232 Port
● Cost-effective Modbus/TCP to RTU/ASCII Gateway
● Supports Modbus/TCP master and slave
● Supports Modbus RTU/ASCII master and slave
● Contains a 32-bit MCU that efficiently handles network traffic
● 10/100 Base-TX Ethernet, RJ-45 x 1 (Auto-negotiating, auto MDI/MDIX, LED Indicators)
● Includes redundant power inputs: PoE (IEEE 802.3af, Class 1) and DC jack
● Allows automatic RS-485 direction control
● Supports TCP, UDP, HTTP, DHCP, BOOTP and TFTP protocols
● Supports UDP responder for device discovery
● Allows easy firmware update via the Ethernet
● Contains a tiny Built-in Web server for configuration
● Terminal block connector for easy wiring
● Tiny form-factor and low power consumption
● RoHS compliant with no Halogen
● Made from fire retardant materials (UL94-V0 Level)
ICPDAS GW-7434DModbus TCP server/DeviceNet Master Gateway
● Programmable DeviceNet Master MAC ID
● Programmable DeviceNet transfer-rate 125K, 250K, 500K
● Supports maximum DeviceNet devices up to 6
● Predefined Master/Slave Connection Set
● The maximum Fragment number is (Input/Output) up to 64
● Supports I/O Operation Mode: Poll, Bit-Strobe and Change Of State/Cyclic
● Supports one Poll, one Bit-Strobe, one COS, one Cyclic IO connection for each DeviceNet device when connected with this module
● Supports on-line adding device into and removing device from network
● Converters single Mobbus/TCP to multi Modbus/RTU, setting by Utility
● Supports VxComm technique for every COM ports of controllers, setting by Utility
● Allowed multi-client (or master) access simultaneously
● Support "Set/Get Explicit Message" methods via Modbus TCP/RTU command
● Supports Modbus RTU to DeviceNet master, setting by Utility
ICPDAS μPAC-7186PEXD-MTCPEmbedded Ethernet / Internet Controller
Modbus Firmware Features:
● Converters single Modbus/TCP to multi Modbus/RTU
● Supports VxComm technique for every COM port of controllers
● Allows multi-client (or master) access simultaneously
● Firmware modifiable
Modbus SDK (in C language) Features:
● Supports extra user-defined command protocol (TCP/IP)
● Register based programming method (easy to use)
● Provides user-defined registers
● Can Iink to Modbus/TCP slave devices
● Can link to Modbus/RTU slave devices
● Can link to non-Modbus/RTU serial devices
● Supports X boards
● Xserver SDK compatible
ICPDAS μPAC-7186PEX-MTCPEmbedded Ethernet / Internet Controller
Modbus Firmware Features:
● Converters single Modbus/TCP to multi Modbus/RTU
● Supports VxComm technique for every COM port of controllers
● Allows multi-client (or master) access simultaneously
● Firmware modifiable
Modbus SDK (in C language) Features:
● Supports extra user-defined command protocol (TCP/IP)
● Register based programming method (easy to use)
● Provides user-defined registers
● Can Iink to Modbus/TCP slave devices
● Can link to Modbus/RTU slave devices
● Can link to non-Modbus/RTU serial devices
● Supports X boards
● Xserver SDK compatible
ICPDAS tGW-715(i) (T) - Tiny Modbus/TCP to RTU/ASCII gateway with PoE and 1 RS-422/485Tiny Modbus/TCP to RTU/ASCII gateway Device Server
● Cost-effective Modbus/TCP to RTU/ASCII Gateway
● Supports Modbus/TCP master and slave
● Supports Modbus RTU/ASCII master and slave
● Contains a 32-bit MCU that efficiently handles network traffic
● 10/100 Base-TX Ethernet, RJ-45 x 1 (Auto-negotiating, auto MDI/MDIX, LED Indicators)
● Includes redundant power inputs: PoE (IEEE 802.3af, Class 1) and DC jack
● Allows automatic RS-485 direction control
● Supports TCP, UDP, HTTP, DHCP, BOOTP and TFTP protocols
● Supports UDP responder for device discovery
● Allows easy firmware update via the Ethernet
● Contains a tiny Built-in Web server for configuration
● Terminal block connector for easy wiring
● Tiny form-factor and low power consumption
● Made from fire retardant materials (UL94-V0 Level)
ICPDAS I-7527DEmbedded communication controller with one RS-485 and seven RS-232 and with 7-segment display
● Built-in "Addressable RS-485 to RS-232 Converter" firmware
● Support about 30 well-defined commands
● Support Dual-Watchdog commands
● Support Power-up value & safe value for DO
● The firmware can real-time monitor the onboard DI and control the onboard DO according to user's requirement
● The firmware can real-time monitor the RS-232 device and control the onboard D/O according to user's requirement
● Watchdog timer provides fault tolerance and recovery
● Low power consumption
● R.O.C. Invention Patent No. 086674, No.103060, No. 132457
ICPDAS I-7527Embedded communication controller with one RS-485 and seven RS-232
● Built-in "Addressable RS-485 to RS-232 Converter" firmware
● Support about 30 well-defined commands
● Support Dual-Watchdog commands
● Support Power-up value & safe value for DO
● The firmware can real-time monitor the onboard DI and control the onboard DO according to user's requirement
● The firmware can real-time monitor the RS-232 device and control the onboard D/O according to user's requirement
● Watchdog timer provides fault tolerance and recovery
● Low power consumption
● R.O.C. Invention Patent No. 086674, No.103060, No. 132457
