PCI Bus I/O Boards
The PCI-M512/PCI-M512U provides battery-backup 512 KB SRAM, 12-bit DI and 16-bit DO. In addition, the PCI-M512U supports both 5 V and 3.3 V PCI bus, while the PCI-M512 supports 5 V PCI bus only. The PCI-M512U (Universal PCI version) is designed as a drop-in replacement for the PCI-M512 (PCI version), so users can replace a PCI-M512 by a PCI-M512U directly without any software or driver modification.
Users can use the DB-16P to connect the input ports (CN2) for isolation purpose, or use DB-16R to interface to the output ports (CN1) for relay control.
The PCI-M512/PCI-M512U is equipped with two Li-batteries to maintain the content of the 512 KB SRAM when PC power loss occurs. The two Li-batteries can continue supplying power to the SRAM to retain the important data for 10 years. The two-battery design also makes it safe to replace new batteries without losing data; when one battery is taken out for replacing a new one, the other continues to provide power to the SRAM.
4 LED indicators on the board are provided for giving clear understanding of the battery states such as normal, low voltage or fault. The PCI-M512/PCI-M512U is an ideal solution for improving system reliability.
-
ICPDAS PCM-CAN200-D
2-Port Isolated Protection CAN Communication PCI-104 Module with 9-pin D-sub connector
● PCI104/PC104+ compliant
● 9-pin D-sub connector
● Compatible with CAN 2.0 parts A and B
● Fully compatible with ISO 11898-2 standard
● Support CAN bard from 10K to 1M bps
● 2500Vrms photo couple isolation on the CAN bus
● Built-in jumper to select 120 ohm terminal resister
● 3KV galvanic isolation
● 2 independent CAN channels
● Direct memory mapping to the CAN controller -
ICPDAS PCM-CAN200P-D
2-Port Isolated Protection CAN Communication PC-104+ Module with 9-pin D-sub connector
● PCI104/PC104+ compliant
● 9-pin D-sub connector
● Compatible with CAN 2.0 parts A and B
● Fully compatible with ISO 11898-2 standard
● Support CAN bard from 10K to 1M bps
● 2500Vrms photo couple isolation on the CAN bus
● Built-in jumper to select 120 ohm terminal resister
● 3KV galvanic isolation
● 2 independent CAN channels
● Direct memory mapping to the CAN controller -
ICPDAS PISO-CAN200-D
2-Port Isolated Protection CAN Communication Board with 9-Pin D-Sub Connector
● Two independent CAN bus 2.0A/2.0B communication ports
● Compatible with CAN specification 2.0 parts A and B
● On-board optical isolation protection
● Programmable transfer rate up to 1 Mbps
● Jumper select 120Ω terminator resistor for each port
● Direct memory mapping to the CAN controllers
● 33MHz 32bit 5V PCI bus (V2.1) plug and play
● PCI card, supports 5V PCI bus -
ICPDAS PISO-CAN200-T
2-Port Isolated Protection CAN Communication Board with 5-Pin Screw Terminal Connector
● Two independent CAN bus 2.0A/2.0B communication ports
● Compatible with CAN specification 2.0 parts A and B
● On-board optical isolation protection
● Programmable transfer rate up to 1 Mbps
● Jumper select 120Ω terminator resistor for each port
● Direct memory mapping to the CAN controllers
● 33MHz 32bit 5V PCI bus (V2.1) plug and play
● PCI card, supports 5V PCI bus -
ICPDAS PISO-CAN400-D
4-Port Isolated Protection CAN Card with 9-Pin D-Sub Connector
● Four independent CAN bus 2.0A/2.0B communication ports
● Compatible with CAN specification 2.0 parts A and B
● On-board optical isolation protection
● Programmable transfer rate up to 1 Mbps
● Jumper select 120Ω terminator resistor for each port
● Direct memory mapping to the CAN controllers
● 33MHz 32bit 5V PCI bus (V2.1) plug and play
● PCI card, supports 5V PCI bus -
ICPDAS PISO-CAN400-T
4-Port Isolated Protection CAN Card with 5-Pin Screw Terminal Connector
● Four independent CAN bus 2.0A/2.0B communication ports
● Compatible with CAN specification 2.0 parts A and B
● On-board optical isolation protection
● Programmable transfer rate up to 1 Mbps
● Jumper select 120Ω terminator resistor for each port
● Direct memory mapping to the CAN controllers
● 33MHz 32bit 5V PCI bus (V2.1) plug and play
● PCI card, supports 5V PCI bus -
ICPDAS PISO-CAN400U-D
4-Port Isolated Protection Universal PCI CAN Card with 9-Pin D-Sub Connector
● Four independent CAN bus 2.0A/2.0B communication ports
● Compatible with CAN specification 2.0 parts A and B
● On-board optical isolation protection
● Programmable transfer rate up to 1 Mbps
● Jumper select 120Ω terminator resistor for each port
● Direct memory mapping to the CAN controllers
● 33MHz 32bit 5V PCI bus (V2.1) plug and play
● Universal PCI card, supports both 5V and 3.3V PCI bus -
ICPDAS PISO-CAN400U-T
4-Port Isolated Protection Universal PCI CAN Card with 5-Pin Screw Terminal Connector
● Four independent CAN bus 2.0A/2.0B communication ports
● Compatible with CAN specification 2.0 parts A and B
● On-board optical isolation protection
● Programmable transfer rate up to 1 Mbps
● Jumper select 120Ω terminator resistor for each port
● Direct memory mapping to the CAN controllers
● 33MHz 32bit 5V PCI bus (V2.1) plug and play
● Universal PCI card, supports both 5V and 3.3V PCI bus -
ICPDAS PISO-CM100-D
One Standalone Intelligent CAN Communication Board
● Microprocessor inside with 80186, 80MHz
● 82C250 CAN transceiver
● SJA1000T CAN controller
● Support both CAN 2.0A and CAN 2.0B
● Timestamp with at least ±1ms precision
● DIP switch to select board number
● Dual port RAM communication mechanism
● RTC (real time clock) inside -
ICPDAS PISO-CM100-T
One Standalone Intelligent CAN Communication Board
● Microprocessor inside with 80186, 80MHz
● 82C250 CAN transceiver
● SJA1000T CAN controller
● Support both CAN 2.0A and CAN 2.0B
● Timestamp with at least ±1ms precision
● DIP switch to select board number
● Dual port RAM communication mechanism
● RTC (real time clock) inside -
ICPDAS PISO-CM100U-D
One Standalone Intelligent CAN Communication Board
● Microprocessor inside with 80186, 80MHz
● 82C250 CAN transceiver
● SJA1000T CAN controller
● Support both CAN 2.0A and CAN 2.0B
● Timestamp with at least ±1ms precision
● DIP switch to select board number
● Dual port RAM communication mechanism
● RTC (real time clock) inside -
ICPDAS PISO-CM100U-T
One Standalone Intelligent CAN Communication Board
● Microprocessor inside with 80186, 80MHz
● 82C250 CAN transceiver
● SJA1000T CAN controller
● Support both CAN 2.0A and CAN 2.0B
● Timestamp with at least ±1ms precision
● DIP switch to select board number
● Dual port RAM communication mechanism
● RTC (real time clock) inside -
ICPDAS PCI-M512
PCI, 512KB Memory Board with DI/DO
● On-board 512K bytes SRAM for PCI-M512/PCI-M512U
● Two Li-batteries, BT1 & BT2, for battery-backup the data of SRAM
● Two indicators, low-battery & bad-battery, for battery BT1
● Another two indicators, low-battery & bad-battery, for battery BT2
● 16-bit general purpose TTL-compatible D/O or relay (with daughter board DB-16R or DB-24PR)
● 12-bit general propose TTL-compatible D/I or isolated input (with daughter board DB-16P)
● PCI-M512U supports 5V and 3.3V PCI bus
SOFTWARE FEATURES:
● DOS Lib and TC/BC/MSC sample program (with source codes)
● DLL and OCX SDK for Windows 98/NT/2000
● DLL and OCX SDK for 32-bit and 64-bit Windows XP/2003/Vista/7
● VB/VC/Delphi/BCB/VB.NET/C#.NET sample programs with source codes are included -
ICPDAS PCI-M512U
Universal PCI, 512KB Memory Board with DI/DO
● On-board 512K bytes SRAM for PCI-M512/PCI-M512U
● Two Li-batteries, BT1 & BT2, for battery-backup the data of SRAM
● Two indicators, low-battery & bad-battery, for battery BT1
● Another two indicators, low-battery & bad-battery, for battery BT2
● 16-bit general purpose TTL-compatible D/O or relay (with daughter board DB-16R or DB-24PR)
● 12-bit general propose TTL-compatible D/I or isolated input (with daughter board DB-16P)
● PCI-M512U supports 5V and 3.3V PCI bus
SOFTWARE FEATURES:
● DOS Lib and TC/BC/MSC sample program (with source codes)
● DLL and OCX SDK for Windows 98/NT/2000
● DLL and OCX SDK for 32-bit and 64-bit Windows XP/2003/Vista/7
● VB/VC/Delphi/BCB/VB.NET/C#.NET sample programs with source codes are included -
ICPDAS PCI-1802HU
32-channel, 12-bit, 40 kS/s High Gain Multi-function DAQ Board (8 K word FIFO)
● 12-bit 330 kHz A/D converter
● AI channels: 32 single-ended/16 differential inputs, 8 K word FIFO buffer
● Up to 44 K samples/s sampling rate
● Programmable high gain: 0.5, 1, 5, 10, 50, 100, 500, 1000
● Three different external trigger: post-trigger, pre-trigger, middle trigger
● Internal/external A/D trigger
● 16 digital input/16 digital output channels
● Two 12-bit DA channels, 2 MHz throughput per channel (max.)
● High speed data transfer rate up to 2.7 Mword/sec.
● DB-889D and DB-1825 accessories for expanding channels
● Half size board
● Universal PCI interface supports both 5 V and 3.3 V PCI bus
● Pull-high/ pull-low resistors for DI channels -
ICPDAS PCI-1802LU
32-channel, 12-bit, 330 kS/s Low Gain Multi-function DAQ Board (8 K word FIFO)
● 12-bit 330 kHz A/D converter
● AI channels: 32 single-ended/16 differential inputs, 8 K word FIFO buffer
● Up tto 330 K samples/s sampling rate
● Programmable low gain: 0.5, 1, 2, 4, 8
● Three different external trigger: post-trigger, pre-trigger, middle trigger
● Internal/external A/D trigger
● 16 digital input/16 digital output channels
● Two 12-bit DA channels, 2 MHz throughput per channel (max.)
● High speed data transfer rate up to 2.7 Mword/sec.
● DB-889D and DB-1825 accessories for expanding channels
● Half size board
● Universal PCI interface supports both 5 V and 3.3 V PCI bus
● Pull-high/ pull-low resistors for DI channels -
ICPDAS PCI-1800HU
32-channel, 32-bit, 44 kS/s High Gain Multi-function DAQ Board (1 K word FIFO)
● PCI bus, 5 V, 32-bit, 33 MHz
● 12-bit 330 kHz A/D converter
● AI channels: 32 single-ended/16 differential inputs, 8 K word FIFO buffer
● Up to 44 K samples/s sampling rate
● Programmable high gain: 0.5, 1, 5, 10, 50, 100, 500, 1000
● Three different external trigger: post-trigger, pre-trigger, middle trigger
● Internal/external A/D trigger
● 16 digital input/16 digital output channels
● Two 12-bit DA channels, 2 MHz throughput per channel (max.)
● High speed data transfer rate up to 2.7 Mword/sec.
● Half size board -
ICPDAS PCI-1800LU
32-channel, 32-bit, 44 kS/s Low Gain Multi-function DAQ Board (1 K word FIFO)
● PCI bus, 5 V, 32-bit, 33 MHz
● 12-bit 330 kHz A/D converter
● AI channels: 32 single-ended/16 differential inputs, 8 K word FIFO buffer
● Up to 330 K samples/s sampling rate
● Programmable low gain: 0.5, 1, 2, 4, 8
● Three different external trigger: post-trigger, pre-trigger, middle trigger
● Internal/external A/D trigger
● 16 digital input/16 digital output channels
● Two 12-bit DA channels, 2 MHz throughput per channel (max.)
● High speed data transfer rate up to 2.7 Mword/sec.
● Half size board -
ICPDAS PCI-1202LU
32-channel, 12-bit, 110 kS/s Low Gain Multi-function DAQ Board (1 K word FIFO)
● 12-bit 110 kHz A/D converter
● 32 single-ended/ 16 differential inputs, 1 K word FIFO buffer
● The total sampling rate is 110 K samples/s for low gain model
● Three external triggers: post-trigger, pre-trigger, middle-trigger
● 16 digital input and 16 digital output channels with 2 M words/s high speed data transfer rate
● Provides programmable low gain: 0.5, 1, 2, 4, 8
● Internal / external trigger
● Two 12-bit independent programmable DACs with 2 MHz throughput per channel (max.)
● Universal PCI card, supports both 5 V and 3.3 V PCI bus
● Digital input port can be set to pull-high or pull-low
SOFTWARE FEATURES:
● DOS Lib and TC/BC/MSC sample program (with source codes)
● DLL and OCX SDK for Windows 95/98/NT/2K
● DLL and OCX SDK for 32-bit and 64-bit Windows XP/2003/Vista/7
● VB/VC/Delphi/BCB/VB.NET/C#.NET sample programs with source codes are included
● LabVIEW toolkit for Windows
● Driver for Linux -
ICPDAS PCI-1202HU
32-channel, 12-bit, 40 kS/s High Gain Multi-function DAQ Board (1 K word FIFO)
● 12-bit 110 kHz A/D converter
● 32 single-ended/ 16 differential inputs, 1 K word FIFO buffer
● The total sampling rate is 40 K samples/s for high gain model
● Three external triggers: post-trigger, pre-trigger, middle-trigger
● 16 digital input and 16 digital output channels with 2 M words/s high speed data transfer rate
● Provides programmable high gain: 0.5, 1, 5, 10, 50, 100, 500, 1000
● Internal / external trigger
● Two 12-bit independent programmable DACs with 2 MHz throughput per channel (max.)
● Universal PCI card, supports both 5 V and 3.3 V PCI bus
● Digital input port can be set to pull-high or pull-low
SOFTWARE FEATURES:
● DOS Lib and TC/BC/MSC sample program (with source codes)
● DLL and OCX SDK for Windows 95/98/NT/2K
● DLL and OCX SDK for 32-bit and 64-bit Windows XP/2003/Vista/7
● VB/VC/Delphi/BCB/VB.NET/C#.NET sample programs with source codes are included
● LabVIEW toolkit for Windows
● Driver for Linux
