Touch LCD Monitor
The newest 7" Touch Screen LCD monitor is developed with latest 4-wire resistive Touch-Screen panel. This 7" monitor has 800 x 480 pixels (2400 x 480 sub-pixels) that help display crystal clear texts and ultra-sharp images through your computer's VGA signal. Use the convenient touch-screen as your input device, control your mouse cursor or the mini on screen keyboard that comes with your operating system. The touch screen utilizes the USB/Serial port as the interface. You can connect several GA-700YY monitors to your computer and the touch screens would work simultaneously through the multi-monitor support.
3 artikel(en)
per pagina
-
ICPDAS Touch 506L
5.7" 4-Gray STN Panel Display with Touch (32-bit RISC CPU)
● Built-in graphic editor software to configure the Touch 506L panel display
● Can import any graphics in BMP format to customize your application
● Display: 5.7” STN LCD
● RTC: Built-in
● Color: 4-Gray
● Resolution: 320(W) x 240(H) dots
● Back light: CCFL x 2 , backlight life time: 50,000 hrs
● Surface Brightness: (cd/m2): 120
● Contrast ratio: 15:1
● Touch accuracy: 1.5 mm
● Touch panel type: 4 wires resistive type
● Serial interface: RS-232 x1 (HMI-PC) , RS-232/485 x1 (HMI-PLC)
● Processor: 32-bit RISC CPU / 200 MHz
● Memory: 4 Mb DRAM, 2Mb Flash Memory
● System Diagnostic: Power failure detection
● Input power: 24V DC, 0.5A maxinum
● Shock (operation): 10 to 25Hz(X,Y,Z direction 2G 30 minutes)
● EMI: Complies with FCC class A
● CE: Complies with EN50081-2 and EN50082-2 standards
● Front panel meets NEMA4 /IP65
● Operation temperature: 0 ~ 45°C
● Operation humility: 10% - 90% , non-condensing
● Dimensions (w x h x d): 204 x 150 x 48mm -
ICPDAS Touch 506T
5.6" 256-color TFT panel LCD Display with Touch (Intel PXA255, 200MHz CPU)
● Built-in graphic editor software to configure the Touch 506T panel display
● Can import any graphics in BMP format to customize your application
● Display: 5.6” TFT LCD
● RTC: Built-in
● Color: 256 color
● Resolution: 320(W) x 234(H) dots
● Back light: CCFL x 1 , backlight life time: 30,000 hrs
● Surface Brightness: (cd/m2) : 500
● Contrast ratio: 150:1
● Touch panel type: 4 wires resistive type
● Light transmission: above 80%
● Life: 1 million activation minimum
● Serial interface: RS-232 x1 (HMI-PC) , RS-232/485 x1 (HMI-PLC)
● Processor: Intel PXA255, 200MHz
● Memory: 4 Mb DRAM, 2Mb Flash Memory
● Compact Flash card slot
● System Diagnostic: Power failure detection
● Input power: 24 VDC, 0.5A maxinum
● Shock (operation) : 10 to 25Hz(X,Y,Z direction 2G 30 minutes)
● EMI: Complies with FCC class A
● CE: Complies with EN50081-2 and EN50082-2 standards
● Front panel meets NEMA4/IP65
● Operation temperature: 0~45 °C
● Operation humility: 10% - 90% , non-condensing
● Dimensions (h x w x d): 204 x 150 x 48mm -
ICPDAS Touch 510T
10.4" Color TFT Panel Display wtih Touch
● Built-in graphic editor software to configure the Touch 510 panel display
● Can import any graphics in BMP format to customize your application
● Max. number of page: 256
● Max. number of object: 5370
● Display: 10.4” high contrast LCD
● Resolution: 640(W) x 480(H) dots
● Display area: 215(W) x 162(H) mm
● Dot size: 0.33 (W) x 0.33 (H) mm
● Back light: CCFT (MTBF, 10,000 hr, w/auto shutdown, replaceable)
● Touch panel: 8 wires resistive type, audible feedback on touch
● Touch Accuracy: 2mm
● Surface hardness: 4H
● Serial interface: RS-232 and RS-485
● Parallel port: Standard Parallel Printer Port
● Surface Brightness: 250 cd/m2 (510S)
● Processor: 32 bit RISC CPU / 133 MHz
● Memory: 4 Mb DRAM, 1Mb Flash ROM
● Input power: 21-28V DC
● EMI: complies with EN50081-2, EN50082-2 & FCC Class A
● Vibration endurance: 10 to 25 Hz ( X,Y, Z direction 2G; 30 minutes)
● Protection structure: IP 65 front panel
● (O ring seal)
● Voltage resistance: 500 VAC (1 min.)
● Isolation resistance: Exceed 50M at 500V DC
● Enclosure: Faceplate (plastic ABS + PC)
● Back cover (plastic ABS + PC)
● Operation temperature: 0~45°C
● Operation humility: 10-90% RH
● Power consumption: 440 mA @ 24V
● Dimensions (h x w x d): 315 x 238 x 62mm
